Hemipsherical Energy Analyzer with MCD Detector for UPS, XPS, ISS and LEISS.

The PHOIBOS 150 Hemispherical Energy Analyzer is a powerful tool for modern photoelectron spectroscopy. This analyzer can be operated in all relevant analysis modes, such as XPS, UPS, as well as AES, ISS and LEISS. Its design and the modular supplementary hardware makes this analyzer the most versatile PES analyzer in the market. It can easily be upgraded with all available SPECS detection systems.

The integrated MCD-9 (9 channel multi channeltron detector) detector is a well established and robust detection solution. The direct detection of electron signals yield quantitative counts per second (cps). With 9 simultaneous channels aquisition with high count rates can be guaranteed.

The energy analyzer section is equipped with 8 customizable entrance and 3 exit slits for UPS and XPS. The analyzer comes with a highly stable power supply, the HSA 3500 plus, for best performance in a wide kinetic energy range up to 3500 eV.


  • Robust and Performant Analyzer for XPS, UPS, AES, ISS and LEIS
  • 150 mm Mean Radius
  • Quantitative Analysis
  • High Count Rate and Linearity
  • 9 Simultaneous Energy Channels
  • Robust Detector Technology
  • Double µ-Metal Shielding




Energy Dispersion by



8 Entrance, 3 Exit slits and Iris aperture

Lens Modes

  • Angular resolved Mode
  • Transmission Mode
  • Spatially resolved Mode
  • Acceptance Angle


    Pass Energies

    0 - 550 eV continously adjustable


    MCD 9

    Energy Window

    23% of Pass Energy

    Kinetic Energy Range

    0 - 3500 eV


    HSA 3500 plus HT 100

    Working Pressure

    10-11 to 10-7 mbar

    Detector Channels


    Measurement Modes

  • Sweeping Mode
  • Fixed Mode
  • Performance
    Angular Resolution

    < 0.5°

    Lateral Resolution

    < 100 µm

    Energy Resolution

    <10 meV for XPS

    XPS Count Rates UHV

    Ag 3d measured with XR 50 300 W MgKa > 3 Mcps @ 0.85 eV, > 9 Mcps @ 1.00 eV

    Mounting Flange

    DN100 CF

    Magnetic Shielding

    Double µ-Metal Shielding

    Working Distance

    40 mm

    Electric Isolation

    up to 7 keV
