1D-DLD Detector

One-Dimensional Multichannel Electron Detector for fast data acquisition and real count rate detection to combine with PHOIBOS 100/150/225 hemispherical analyzer for XPS, UPS, ISS, LEIS measurements.

Nowadays an extremely fast data acquisition is mandatory for many experiments. The fastest way is snapshot operation giving a complete spectrum without scanning the energy. The new one dimensional Delayline detector 1D-DLD for the PHOIBOS 100/150 developed by Surface Concept and integrated by SPECS combines a convenient number of parallel channels for fast snapshot operation (124 or 200 channels), highest count rates at excellent energy resolution in scanned and snapshot mode, true count rate detection, and a high dynamic range of 106, all available at an attractive price.

KEY FEATURES

  • PHOIBOS 100/150 Detector Upgrade to 124/200 Parallel Channel Detection
  • Scanned Mode or Snapshot Mode Operation
  • Highest Count Rates at Excellent Energy Resolution
  • Save 90 % Acquisition Time in Snapshot Mode. -Outstanding Linearity and Dynamics
  • Real Count Rates for Reliable Quantification
  • Excellent Time Resolution for Dynamic Experiments

MADE FOR THESE METHODS

4

SPECIFICATIONS

1D-DLD Detector
Operation
Number of Channels

400, 100 (binning 4), 50 (binning 8) for PHOIBOS 100
960, 240 (binning 4), 120 (binning 8) for PHOIBOS 100

Active Detector Area

40 mm for PHOIBOS 100
65 mm for PHOIBOS 150/225

Type of Detector

Delay Line

Compatible with

PHOIBOS 100/150/225

Operation Modes

Performance
Max. Count Rate

> 12 Mcps

Linearity

> 9 Mcps

Time Resolution

< 240 ps

Noise

< 20 cps (all channels)

Mounting
Mounting Flange

DN100 CF, DN150 CF

RELATED PRODUCTS

1

SPARE PARTS

1
Product image
Product description
Article No.

DN40CF 4-fold SMB Feedthrough for DLD

Spare electrical feedthrough for all DLD detectors. Connection flange for the ACU unit

2100011768
