PHOIBOS 225 HV 2D-DLD

Ultra High Energy Hemispherical Energy Analyzer with 2D DLD Detector for HAXPES up to 15 keVwith 225 mm mean radius

The PHOIBOS 225 HV hemispherical energy analyzer is an ultra high kinetic energy analyzer solution for photoelectron spectroscopy on the material science edge. This analyzer can be operated in all relevant analysis modes, such as ARPES, XPS, UPS, as well as AES, ISS and LEISS. Its design and the modular supplementary hardware makes this analyzer the most versatile PES analyzer in the market. Its unique design allows stabe measurements up to 15 keV kinetic energy for highest XPS sensitivity in layered materials and deep core ESCA.

With a 2D DLD HV detector is shows outstanding performance in countrate, linearity and an ultrafast single event countingmechanism. It combines a state of the art lens system with a proven hemipshere design for highest transmission and kinetic energy stability. The analyzer can be operated in transmission (XPS/UPS), angular resolved (ARPES) and magnification mode (slab imaging).

The energy analyzer sectionis equipped with 8 customizable entrance and 3 exit slits. The analyzer comes with a special and highly stable power supply, the AVC 15000, for best performance in anb extreme kinetic energy range.

A classical CCD camera detection system is available on request.

KEY FEATURES

Stable High Voltage Operation up to 15 keV
Precise and Stable Power Supply
Ultra Fast HV 2D DLD Detector with Single Event Counting
Angular and Transmission Lens Modes
Snapshot and Sweeping Spectra Aquisition

MADE FOR THESE METHODS
SPECIFICATIONS
PUBLICATIONS
SPARE PARTS
DOWNLOADS

MADE FOR THESE METHODS

2

HAXPES

Hard X-ray Photoelectron Spectroscopy can provide information about chemical composition in the bulk of a material, rather than in the surface.

ARPES

Angle-Resolved Photoelectron Spectroscopy detects the energy and angle distribution of photoelectrons to determine the electronic structure of solids.

SPECIFICATIONS

PHOIBOS 225 HV 2D-DLD

Operation

Kinetic Energy Range	0-7000 eV
Pass Energies	0-550 eV Continously Adjustable
Energy Dispersion	Hemisphere
Lens Modes	Transmission Mode, Angular Resolved Mode, Magnification (Lateral Resolved) Mode
Measurement Modes	Snapshot Mode, Sweeping Mode, Fixed Energy Mode
Detector	2D DLD Detector
Slits/Apertures	8 entrance and 3 exit slits and iris aperture
Energy Window	9% of Pass Energy
Electronics	HSA 7000
Working Pressure	10^-11 to 10^-7 mbar

Performance

Energy Resolution	< 2 meV in UPS < 7 meV in XPS <15 meV in HAXPES
Angular Resolution	< 0.1°
k-Resolution	N/A
Acceptance Angle	±15°, ±7°, ±4° and ±3°
Lateral Resolution	< 35 µm
Smallest Acceptance Spot	100 µm
XPS Count Rates UHV	tba
Detector Channels	1000 x 800 (with Channel Binning)
