UVS 300

Duoplasmatron Discharge Light Source with Quartz Capillary

The UVS 300 is a real and unique duoplasmatron type discharge VUV light source. The discharge spot is confined to a small area, which makes this source the only available point source on the market. The dispersive quartz capillary is optimal for illuminating large areas on the surface to acess UPS and APRES from medium and large samples. The UVS 300 is compatible with the TMM 304 UV monochromator. The duoplasmatron design allows emission from very low gas pressure, yielding in the highest available He I to He II emission intensity ratio.

KEY FEATURES

  • Real Duoplasmatron Discharge Light Source
  • Large Area Coverage of the Beam
  • Compatible with UV Monochromator
  • Excellent He II intensity
Back to top

MADE FOR THESE METHODS

1
Back to top

RELATED PRODUCTS

14
Back to top

APPLICATION NOTES

Back to top

SPARE PARTS

10
Product image
Product description
Article No.

Membrane for VAT leak valve

Replacement membrane for VAT leak valve

2100010186
piezo actor

Replacement Piezo actor for SPECS Piezo Gas Inlet system

2060005909
variable leak valve DN16CF-R

New VAT leak valve

2060015126
Filament ceramic UVS 300

Replacment filament ceramic for SPECS UVS 300 filament assembly. 4 pieces needed.

2000532013
Gasket ring O-Ring 15 x 5 Vi500

Replacement O-Ring for SPECS UVS 300 source 15 x 5

2070000307
Marcor-cylinder for anode of UVS 300

Replacement Marcor cylinder for the anode assembly of SPECS UVS 300 source

2000532026
Quartz Capillary, id 1.0 mm, od 5.0 mm

Quartz capillary for SPECS UVS 300 source with inner diameter of 1.0 mm. Length can be customized

2000532050
Quartz capillary, id=1.5 mm, od=5.0 mm for UVS 300

Quartz capillary for SPECS UVS 300 source with inner diameter of 1.5 mm. Length can be customized

2000532051
Quartz capillary, id=2.0 mm, od=5.0 mm for UVS 300

Quartz capillary for SPECS UVS 300 source with inner diameter of 2.0 mm. Length can be customized

2000532108
Tungsten cathode for UVS 300

Exchange cathode for SPECS UVS300 source. Recommended exchange interval one year.

2000535050
