PHOIBOS 150 WAL 2D-DLD

Wide Angle Analyzer for ARXPS with 150 mm Mean Radius with 2D DLD detector and ±30° Accpetance Angle.

The PHOIBOS 150 hemispherical energy analyzer is a powerful tool for modern photoelectron spectroscopy. This analyzer can be operated in all relevant analysis modes, such as XPS, ARPES, as well as AES, ISS and LEISS. Its design and the modular supplementary hardware makes this analyzer the most versatile PES analyzer in the market. It can easily be upgraded with all available SPECS detection systems.

Its special wide angle lens covers the range of ±30° to efficiently cover the relevant wide angular range for angular resolved XPS. That allows to measure the depth profile of a sample at up to 3500 eV kinetic energy without sample destruction. Also ARPES (UV Range) with an identical accpetance angle is possible.

The integrated 2D-DLD detector is an ultrafast 2D single event detection system. The direct detection of electron signals yield quantitative counts per second (cps) in the energy and angular/second dimension. The powerful electronics can aquire ultrafast snapshot measurements of the energy spectrum with up to 1000 energy (anguklar channels as well as continous sweeping energy spectra. Its low dark count rate and high linearity make this detector outstanding for XPS analyis.

The energy analyzer sectionis equipped with 8 customizable entrance and 3 exit slits. The analyzer comes with a highly stable power supply, the HSA 3500 plus, for best performance in a wide kinetic energy range.

KEY FEATURES

  • ±30° Acceptance Angle for ARPES(XPS)
  • Double µ-Metal Shielding
  • Up to 3500 eV Kinetic Energy
  • Desctruction Free Depth Profiling
  • 150 mm mean Radius
Back to top

MADE FOR THESE METHODS

2
Back to top

SPECIFICATIONS

PHOIBOS 150 WAL 2D-DLD
Performance
Energy Resolution

< 2.5 meV ultimate resolution

Angular Resolution

< 0.5° for 200 µm spot size

k-Resolution

N/A

Acceptance Angle

±30°

Lateral Resolution

N/A

Smallest Acceptance Spot

N/A

XPS Count Rates UHV

< 60 kcps @ 520 meV FWHM (Ag3d Al ka)

Detector Channels

1000 x 800 (with Channel Binning)

Operation
Kinetic Energy Range

0-3500 eV

Pass Energies

0-200 eV Continously Adjustable

Energy Dispersion

Hemisphere

Lens Modes

Transmission Mode, Angular Resolved Mode

Measurement Modes

Snapshot Mode, Sweeping Mode, Fixed Energy Mode

Detector

2D DLD Detector

Slits/Apertures

8 entrance and 3 exit slits and iris aperture

Energy Window

13% of Pass Energy

Electronics

HSA 3500 +

Working Pressure

10-11 to 10-7 mbar

Mounting
Working Distance

27.75 mm

Mounting Flange

DN150CF (8" OD)

Electric Isolation

> 10 keV

Magnetic Shielding

Double µ-Metal Shielding

Back to top

SPARE PARTS

2
Product image
Product description
Article No.

Channelplates set (1 pair MCP) for DLD detector

Spare channelplate set for 1D & 2D-DLD 100 & 2D-DLD 150. Not suitable for 1D-DLD 150

2060011380
DN40CF 4-fold SMB Feedthrough for DLD

Spare electrical feedthrough for all DLD detectors. Connection flange for the ACU unit

2100011768
