PHOIBOS 100 Classic MCD

Price efficient Hemipsherical Energy Analyzer with 1D-MCD detector for UPS, XPS, ISS and LEISS.

The PHOIBOS 100 Classic hemispherical energy analyzer is price efficient for modern photoelectron spectroscopy. This analyzer can be operated in all relevant analysis modes, such as XPS and AES, ISS and LEISS. Its design and the modular supplementary hardware makes this analyzer the most versatile PES analyzer in the market. It can easily be upgraded with all available SPECS detection systems.

This analyzer comes with a single µ-metal shielding, providng the best ratio between XPS performance and budget.

The integrated MCD-5 (5 channel multi channeltron detector) detector is a well established and robust detection solution. The direct detection of electron signals yields quantitative counts per second (cps). With 5 simultaneous channels, aquisition with high count rates can be guaranteed.

The energy analyzer section is equipped with 8 customizable entrance slits and 3 exit slits for UPS and XPS. The analyzer comes with a highly stable power supply, the HSA 3500 plus, for best performance in a wide kinetic energy range up to 3500 eV.

KEY FEATURES

  • 100 mm Mean Radius
  • Quantitative Analysis
  • Robust Detector Technology
  • Fast Snapshot Measurements
  • Single µ-Metal Shielding
Back to top

MADE FOR THESE METHODS

2
XPS, Chemical Mapping
X-ray photoelectron spectroscopy (XPS) is a widely used method for chemical analysis. By surface imaging or mapping a chemical map can be recorded
AES, SAM, SEM
Auger electron spectroscopy/microscopy detects the energy distribution of secondary electrons returning from a surface locally for chemical analysis.
Back to top

SPARE PARTS

7
Product image
Product description
Article No.

5-Channeltron-Detection Unit for PHOIBOS 100

Refurbished and tested MCD-5 detector for PHOIBOS 100

2011500451
Channeltron-Array set (5)

Replacement for 5-channel channelron detector MCD-5 for PHOIBOS 100

2079150301
Cu gasket DN370CF for PHOIBOS 100

PHOIBOS 100 analyzer main flange gasket for Releases R3, R6, R7

2060000572
Cu gasket for PHOIBOS 100

PHOIBOS 100 analyzer main flange gasket for Releases R5

2070000338
Rotary feedthrough for IRIS

Replacement feedthrough for PHOIBOS Release R5 & R6 iris mechanism

2060001175
Spindle with Spur and Bevel Gear for Iris

Replacement spindle for PHOIBOS Release R5 & R6 iris mechanism

2055021656
Tubus 3 with Iris

Replacement iris mechanism for PHOIBOS Release R5 & R6

2079150291
