FG 22/35

Low Energy Electron Source for Sample Neutralization

The FG 22/35 is a compact, easy to handle, reliable flood gun for charge neutralization of positively charged insulators or semiconductors. It allows operation in the energy range of 0 - 500 eV for charge compensation in typical XPS/AES and SIMS experiments, respectively.

KEY FEATURES

  • High electron beam current
  • Energy range 0 - 500 eV
  • Stabilized emission

MADE FOR THESE METHODS

1

SPECIFICATIONS

FG 22/35
Operation
Electron Current

> 1 μA

Electron Energy

0-500 eV

Scannable

-

Applications

XPS, AES, SIMS

Optional Accessories

-

Performance
Scan Range

-

Spot Size

15-25 mm at 40 mm

Mounting
Mounting Flange

DN35CF (2.75”)

Insertion Depth

146 mm

Working Distance

40 mm

Power Supply

FG-500 A

RELATED PRODUCTS

1

APPLICATION NOTES

SPARE PARTS

1
Product image
Product description
Article No.

Tungsten filament for RHEED and FG 22

Replacement cathode for FG22/35 and RHEED

2060004171
