EBE-S

Highly Reliable Power Supply for EBE-1 Single-Pocket E-Beam Evaporator

The SPECS EBE-S is a highly reliable analogue power supply for EBE-1 single-pocket e-beam evaporator.The power supply is designed to evaporate the thickest rods (6 mm) and is robust enough to survive misuse without dire consequences seen in more complex failure prone electronics. The unit has remote control interface and is suitable for high precision HV and filament control for improved low rate evaporation as well as for high power evaporation for thicker rods or larger crucibles and high rate evaporation.

KEY FEATURES

  • 400 W power supply and controller
  • Analogue input for filament control
  • Power supply with intelligent front plate for control of filament current or flux
  • Remote control interface
  • High precision HV and filament control for improved low rate evaporation
  • High power evaporation for thicker rods or larger crucibles and high rate evaporation

MADE FOR THESE METHODS

1

SPECIFICATIONS

EBE-S
Operation
Number of Pockets

1

Water Cooling

internal

Max. Power

400 W

Operating Pressure

< 10-10 - 10-5 mbar

Optional Accessories

Non standard lengths 150 - 500 mm

Electric motorization of manual shutter

0.25 cc crucibles from C, Mo, Ta and W

Flux measurement electrode and feedthrough

Thermocouple (Type C) and feedthrough

Mounting
Mounting Flange

NW35CF (2.75 ")

Insertion Depth

200 mm

Max. Rod Diameter

6 mm

Max. Rod Feed

50 mm

Max. Crucible Size

0.25 cc

Power Supply

400 W

Shutter

optional

Flux Monitor

optional

RELATED PRODUCTS

4

SPARE PARTS

14
Product image
Product description
Article No.

Crucible EBE-1-C-C

Crucible EBE-1-C-C for electron beam evaporator EBE-1. Material: pyrolytic graphite. Volume: 0.25 cc

2055003898
Crucible EBE-1-C-Mo

Crucible EBE-1-C-Mo for electron beam evaporator EBE-1. Material: Molybdenum. Volume: 0,25 cc

2055003902
Crucible EBE-1-C-Ta

Crucible EBE-1-C-Ta for electron beam evaporator EBE-1. Material: Tantalum. Volume: 0,25 cc

2055003904
Crucible EBE-1-C-VCvitreous carbon

Crucible EBE-1-C-VC for electron beam evaporator EBE-1. Material: Vitreous Carbon. Volume: 0,25 cc

2055003900
Crucible EBE-1-C-W

Crucible EBE-1-C-W for electron beam evaporator EBE-1. Material: Tungsten. Volume: 0,25 cc

2055003906
EBE-1 crucible with lid C-Mo

Crucible EBE-1-C-Mo with lid for electron beam evaporator EBE-1. Material: Molybdenum

2055003911
EBE-1 crucible with lid C-Ta

Crucible EBE-1-C-Ta with lid for electron beam evaporator EBE-1. Material: Tantalum

2055003913
EBE-1 crucible with lid C-VC vitreous carbon

Crucible EBE-1-C-VC with lid for electron beam evaporator EBE-1. Material: Vitreous Carbon

2055003910
EBE-1 crucible with lid C-W

Crucible EBE-1-C-W with lid for electron beam evaporator EBE-1. Material: Tungsten

2055003917
Rod holder EBE-1-RH2

Rodholder EBE-1-RH2 for electron beam evaporator EBE-1 for 2 mm rods including screws

2055003889
Rod holder EBE-1-RH3

Rodholder EBE-1-RH3 for electron beam evaporator EBE-1 for 3 mm rods including screws

2055003891
Rod holder EBE-1-RH4

Rodholder EBE-1-RH4 for electron beam evaporator EBE-1 for 4 mm rods including screws

2055003893
Rod holder EBE-1-RH5

Rodholder EBE-1-RH5 for electron beam evaporator EBE-1 for 5 mm rods including screws

2055003895
Filament for EBE-1

Replacement filament for EBE-1

2055002208
