CCX 70

Isolation Unit for XR 50 X-Ray Source

CCX 70 is an isolation unit for XR 50 X-ray source  with integrated safety electronics for both people and equipment protection, sensors for water temperature, flow and water pressure and easily replaceable particle filters.

KEY FEATURES

  • Integrated safety electronics for both people and equipment protection
  • Sensors for water temperature, flow and water pressure
  • Easy replaceable particle filters
  • 2 height units case for 19 inch electronic racks
Back to top

MADE FOR THESE METHODS

2
Back to top

SPARE PARTS

11
Product image
Product description
Article No.

Cable set RAP plug CCX70

Replacement red HV cable for CCX70 with bridgecable within RAP plug

2100015948
CCX 60 filter front side(Plastic nut + nylon filter)

Replacement set of plastic nut and nylon filter for CCX 60 and CCX 70. Should be exchanged in case the nut is worn out. Two pieces needed.

2055021880
Coupling (white) at the PTFE-pipe

Tube connection between sacrificial anodes and white Teflon tube for all XR50 and XR-MF head cooling. Replacement in case of a leak at the coupling. Two pieces needed.

2060016073
Coupling for x-ray source RQ 20/38 and XR 50

Replacement quick coupling for all XR 50 with tube connection 11 mm. Needed for XR50 bypass head cooling and some SPECS chiller. Recommended replacement intervall is two years.

2074500005
Filter housing F10-1/4"

Replacement filter housing for all CCX. Blue filter housing for the water lines

2074300227
Filter Nylon 50 ┬Ám(for blue housing and front side)

Replacement Nylon particle filter for all CCX devices. Three pieces needed. Recommended Exchange interval is one year

2074300867
Flowmeter for CCX60 SN 175-09.02 and higher

Replacement flowmeter for CCX60 release 2 from SN 175-09.02 and CCX70

2084000254
Quick coupling for x-ray source

Replacement quick coupling for all XR 50, with threads for scrificial anode. Two pieces needed. Recommended exchange intervall every two years together with sacrificial anodes

2074500142
Male quick connector with 11 mm tube connection for Walther coupling

Male quick connector with 11 mm tube connection for Walther coupling

2074500006
Sacrificial anode

Sacrificial anodes to be used for CCX 70. Two pieces needed. Recommended exchange interval is two years

2055024811
Unbowed Srew fastening 8-1/4"

Connector between sacrificial anode and white PTFE pipe for all CCX

2074300679
