PMD4 piezo motor driver

High performance piezo motor driver for any type of piezo motor

piezo motor driver PDM4 von Nanonis
Nanonis 8- or 16-channel, high-current piezo motor driver

The Nanonis PMD4 was specifically designed with low-temperature applications in mind, where slip-stick motors require very fast slip-transitions. The patented electronics of the PMD4 can provide waveforms with up to ±400V and deliver peak currents above 20 A. This results in fast transitions taking significantly less than 1 μs even at peak voltage into a real load. The very sharp transitions and high voltages also allow for simpler piezo stacks resulting in more rugged mechanical designs. The PMD4 can drive loads up to 3 μF.

In the standard configuration one generator is multiplexed to 8 output lines. Configurations with 16 output lines or two independent generators for opposing or delayed voltage ramps are possible.The output channels can be run individually or in parallel. The ground concept allows for different configurations and ensures absolute silence on the piezos when the motors are not running.


  • Patented electronics with peak currents above 22 A
  • Drives loads of up to 3 µF
  • 8 or 16 output lines
  • Up to 800 V peak-peak amplitude
  • Single or dual signal generators
  • extremely sharp ramp edge
  • Specifically designed for low-temperature setups

PMD4 versions

The following PMD4 versions are available:

Namepart numberWaveformNumber of outputsPeak current
PMD4a2011751012Single822 A
PMD4aO2011751031Single84 A
PMD4c2011751013Single1622 A
PMD4cO Single164 A
PMD4b2011751052Dual with opposite polarity822 A
PMD4d2011751070Dual with relative delay822 A
