FOCUS EFM 3T

Mounted on a DN40 (2 ¾”) flange, the EFM 3T offers the option of sequential or co-deposition of up to 3 materials. The benefits of the classic single source are maintained including linear rod retraction and independent flux monitoring.

Based on the design concept of the EFM 3 evaporators, the triple evaporator EFM 3T features three independent cells for the evaporation of a wide range of materials from wires, rods or crucibles.

The three individual cells have crossing beams at about 93 mm distance from the exit aperture (254mm from the mounting flange) to ensure a maximum overlap of the evaporation area.

Each cell is equipped with a separate filament and HV supply to prevent crosstalk. Three independent flux monitors enable the controlled stoichiometric growth of compounds.

The integral multi-position shutter enables precise dosing and simultaneous or consecutive evaporation to produce e.g. super lattices or multilayers.

The latter is easily accomplished by means of the optional shutter motorization and the PC software tool Multi Epitass.

The deposition area is governed by the choice of one of three apertures. The three evaporation targets are independently mounted on three 25 mm Z-shifts for alignment. This feature allows evaporation from rods with a multi-pocket instrument. The target materials can be easily refilled from the rear (3x NW 16 CF).

One power supply can operate all three cells sequentially. In case of co-evaporation each material requires a separate power supply.

KEY FEATURES

  • Evaporation area Ø 8.5, 11 and 15 mm
  • Working distance 93 mm (± 10 mm)
  • 3 independent cells/ filaments/ flux monitors
  • No crosstalk during compound growth
  • Flux monitor
  • Integrated multi-position shutter
  • Mounting flange NW 35 CF
  • All other features same as EFM 3.

MADE FOR THESE METHODS

1

SPECIFICATIONS

FOCUS EFM 3T
Operation
Number of Pockets

3

Water Cooling

internal

E-beam power

300 W

Operating Pressure

< 10-10 - 10-5 mbar

Optional Accessories

Non standard lengths

Mounting
Mounting Flange

NW35CF (2.75 ")

Insertion Depth

210 mm

Max. Rod Feed

25 mm

Power Supply

300 W

Shutter

Motorized shutter
