THEMIS 600 2D-DLD

Time-of-Flight Electron Energy Analyzer for ARPES and 2D DLD Detector and 600 mm Drift Tube

The SPECS THEMIS is a time-of-flight analyzer, ideally suited for pulsed light sources with high repitition rates. The electron dispersion is done by the different travel time through the drift tube, when a bunch of electrons is emissted from a short laser pulse. Depending on the kinetic energy window, an ultra high resolution in the sub-meV range can be detected.

The detection system is the 2D DLD detector with x and y detection for angular resolved data and integrated 240 ps time resolution. The native repition rate is 5-8 MHz and an optional frequency entension to 50-80 MHz is available.

The THEMIS 600 comes with a 600 mm drift tube. The lens system, beeing identical to the PHOIBOS 100/150 fits into a DN100CF flange.

KEY FEATURES

  • Parallel Energy and Angular Detection
  • Up to ±15° Acceptance Angle
  • 2D DLD Detector with 240 ps Time Resolution
  • Up to 3500 eV Kinetic Energy
  • 600 mm Drift Tube
