PHOIBOS 225 2D-CMOS with 3D(2D) Spin Mott Detector
Ultra High Resolution Hemispherical Energy Analyzer with 2D CMOS Detector for XPS, ARPES, ISS and LEISS and VLEED Detector for Spin Measurements with 225 mm Mean Radius
The PHOIBOS 225 hemispherical energy analyzer is ultra high resolution analysis solution for photoelectron spectroscopy. This analyzer can be operated in all relevant analysis modes, such as ARPES, XPS, UPS, as well as AES, ISS and LEISS. Its design and the modular supplementary hardware makes this analyzer the most versatile PES analyzer in the market.
The patented design of the detector section allows measurements of all three spin components and subsequent 2D ARPES merasurements. The 2D detector is a full scale 2D CMOS detector un undiminished performance in standard PES. The spin channel consist of a 90° deflector to acess the ut of plan spin component and a special rotator lens to swich between the two in plance components of the spin.
The actual spin detector is based on the Rice University mini Mott scheme, where a thin tungesten target on high voltage (25 kV) is used as a spin selective scattering target. With the Mott detector it is possible to measure 4 channels in one experminet (two spin components with spin up/down, respectively).
The energy analyzer sectionis equipped with 8 customizable entrance and 3 exit slits. For highest energy resolution the entrance slit can be chosen down to 50 µm, providing achievable energy resolution better than 1 meV. The analyzer comes with a highly stable power supply, the HSA 3500 plus, for best performance in a wide kinetic energy range.
A classical CCD camera detection system is available on request.
- High Performance Analyzer for XPS, ARPES, AES, ISS and LEIS
- Energy resolution better than 1 meV
- Angular Resolution better than 0.1°
- Double µ-Metal Shielding
- Highly Sensitive Spin Detector
- Exchange Scattering Scheme
- Full Scale 2D Detector
- Spin Rotator and 90° Deflector
< 1 meV in ARPES Mode
< 0.1° in ARPES Mode
±15°, ±7°, ±4° and ±3° in ARPES Mode
< 35 µm
|Smallest Acceptance Spot|
|XPS Count Rates UHV|
1285 x 730 (with Channel Binning)
|Sherman Function /FoM|
Sherman Function: 0.16
|Kinetic Energy Range|
0-3500 eV in PES
0-550 eV Continously Adjustable
Transmission Mode, Angular Resolved Mode, Magnification (Lateral Resolved) Mode
Snapshot Mode, Sweeping Mode, Fixed Energy Mode
2D CMOS Detector
8 entrance and 3 exit slits and iris aperture
9% of Pass Energy
HSA 3500 +
10-11 to 10-7 mbar
DN150CF (8" OD)
Double µ-Metal Shielding
> 15 keV
Spare channelplate set for all 40 mm CCD detectors
Spare phosphor screen for all 40 mm CCD detectors. Exchange with channelplates is recommended.
PHOIBOS 225 analyzer main flange gasket. Please report SN before ordering
Replacement feedthrough for PHOIBOS Release R5 & R6 iris mechanism
Replacement spindle for PHOIBOS Release R5 & R6 iris mechanism
Replacement iris mechanism for PHOIBOS Release R5 & R6
Single replacement channeltron for SPECS MOTT spin detector
Replacement channeltron set for SPECS MOTT spin detector
