Mini Microwave Plasma Cracker Source for the Hybrid Generation of Atoms and Ions from Nitrogen or Reduced Nitrogen Gases in Small Vacuum Chambers
The hybrid plasma source for nitrogen or other reduced nitrogen gases MPS-ECR-HN is a fully UHV compatible component for most demanding MBE applications and surface modifications, suitable for a wide range of vacuum levels (UHV to HV) in small vacuum chambers. Microwaves with a frequency of 2.45 GHz are generated by a microwave magnetron and coupled into the plasma chamber, where a plasma is excited and the microwaves absorbed. The plasma density is enhanced by the magnetron cyclotron resonance effect, provided by a 86 mT magnetic quadrupole arranged around the plasma chamber. The electrons undergo electron cyclotron resonance (ECR) motion, which greatly enhances the electron path length and therefore the probability of collision with other molecules and subsequent ionisation.This hybrid source combines atom source and ion source characteristics to produce a source, which behaves like the atom source until potentials are applied to the extraction grids, when nitrogen ions with controllable energy (50 - 1500 eV) are then added to the beam.
The source is fully bakeable with outstanding cooling from a full length water-jacket. With additional sets of the user-exchangeable extraction grids or aperture plates, the source can be easily reconfigured for reducing gases or as an atom source, downstream plasma source or hybrid source. The small mounting flange (DN40CF) makes the source suitable where space constraints are an issue.
- Small mounting flange
- Filamentless design permits operation with reactive gases
- No microwave tuning required
- Unique integrated shutter and current monitor option
- Trivial bakeout preparation ~1 minute
- Integral water cooling jacket
Microwave assisted plasma source
60 W max. at 2.45 GHz
|Gas Flow Rate|
< 0.1 sccm to 100 sccm (mode dependant)
< 10-7 - 10-5 mbar
~13 mm at source
NW40CF (2.75 ")
